ASI Architectural Microperf Ceilings & Walls
Microperf Ceilings & Walls
MICROPERF CEILINGS & WALLS
Microperf ceiling and wall panels use cutting-edge acoustical technology, enabling sound mitigation without the look or feel of typical absorber panels. Engineered to appear like a standard millwork panel, they have excellent sound absorption properties.
Their lightweight design allows panels to be mounted in a variety of methods. Built with a fiberglass core, Microperf panels are available in wood veneer, vinyl, and can be painted or stained to match.
INFORMATION
BRAND
ASI Architectural
PROPERTIES
Acoustic Insulation
CORE/FIRE RATING
Class A Fire Rating
DOWNLOAD
↓ Data Sheet
FORMAT
- Slabs
- Plates
- Panels
USE
- Walls
- Interior
- Ceilings
- Decoration
APPLICATIONS
- Cultural
- Corporate
- Residential
- Commercial
PERFORATION
- Surface Diameter: 0.5mm
- Pattern: Offset
CERTIFICATION
Fire Rating: Class A (ASTM-E84)
APPEARANCE
Suspended from 1″ tubular steel frames with “D” rings
SIZES
- Panel thickness: 3/4″, 1″
- Maximum width/length: 5′ x 12′
WEIGHT
- ¾”: 1.2 lbs. / sq. ft.
- 1″: 1.3 lbs. / sq. ft.
ACOUSTICAL ABSORPTION
- Microperf 3/4″: NRC Rating .70
- Microperf 1″: NRC Rating .90
CHARACTERISTICS
- Rigid
- Lightweight
- Impact resistant
- Various finish options
FINISHES
Clear lacquer top coat, Class-A varnish, or stained to match -Touch-up finish available for field application
MOUNTING OPTIONS
- Walls: Z-clip / Z-Bar
- Ceilings: Lay-in or tegular lay-in; torsion spring
APPLICATION AND USE IN CONSTRUCTION
-Walls -Ceiling -Interior
APPEARANCE & COLOR
- Face options: real wood veneer or vinyl
- Available in wood veneer in the species shown below*
- Low reactivity to seasonal changes in temperature and humidity
- Uncompromised aesthetics -Lightweight, impact resistant, and rigid
- Can be hung like traditional wall panels using z-clips or installed on HD T-Bar grid
MICROPERF LAY IN
- Standard panel sizes can be field cut to fit irregular shaped installations
- Lays in to HD 15/16” T-bar grid for 100% accessibility
MICROPERF METAL
- Standard panel sizes can be field cut to fit irregular shaped installations
- Lays in to HD 15/16” T-bar grid for 100% accessibility
- Tegular panels have a 1” reveal
- Black, White and Anodized finishes are available
- Does not require and Acoustical Backer to achieve an NRC rating
MICROPERF PANELS
For ceilings and walls
- Attaches to HD 15/16” T-bar grid with clips for 100% accessibility
- Standard panels can be field cut to fit installation
- Custom sizes available to fit irregular installations
MICROPERF TEGULAR
- Standard panel sizes can be field cut to fit irregular shaped installations
- Lays in to HD 15/16” T-bar grid for 100% accessibility
- Tegular panels have a 1” reveal
FINISHES
-Ash -Walnut -Maple -Beech -Red Oak -White Oak -Hickory -Cherry -Natural Bamboo -Caramelized Bamboo
