Nelissen Old-haspengouw Bricks
OLD-HASPENGOUW BRICKS
OLD-HASPENGOUW BRICKS
A hand moulded facing brick with a classic look and feel
The facade bricks (non-perforated) have five sand covered sides and one side with possible oblong groove.
The structure looks rugged with fine and irregular grooves in the sandy surface. The baking process takes place in a gas-heated tunnel oven under slightly reduced atmosphere.
The brick has a reddish base. The typical old aspect is the result of the wet and unbaked bricks’ treatment with various admixtures.
In addition, the various types of sand are responsible for calcareous sediments slightly diminishing the red colour. The hues range from soft red to dark red with beige, white and grey shadings. The colours shown are a near reflection of reality.
INFORMATION
TOLERANCE CATEGORY
T2
GROSS DRY DENSITY
D1 : 1630 Kg/m³
WATER VAPOUR PERMEABILITY
5/10
FREEZE/THAW RESISTANCE
F2
WATER ABSORPTION
14 %
REACTION TO FIRE
A1
ACTIVE SOLUBLE SALTS
S1
INITIAL WATER ABSORPTION
1.5<IW<=4 Kg/(m².min)
BRAND
Nelissen
PRODUCT TYPE
Bricks
THERMAL CONDUCTIVITY(Λ10,DRY,MAT(90,90)
S2 : 0.59 W/mK
THERMAL CONDUCTIVITY(Λ10,DRY,MAT) EN1745 ANNEX A
S1 : 0.55 W/mK
DIMENSIONS
| SIZES | M50 | M65 | N70/4 | N70/5 | N70/7 | NNF | RF | WV50 | WV65 |
|---|---|---|---|---|---|---|---|---|---|
| Length | 188 mm | 188 mm | 239 mm | 239 mm | 240 mm | 241 mm | 208 mm | 209 mm | 213 mm |
| Width | 88 mm | 88 mm | 72 mm | 72 mm | 70 mm | 108 mm | 100 mm | 100 mm | 101 mm |
| Height | 51 mm | 64 mm | 40 mm | 50 mm | 70 mm | 73 mm | 40 mm | 49 mm | 65 mm |
