Oikos Synua Door

Sat Aug 06, 2022Entrance DoorsConstruction= No DesignerOikos Venezia, S.r.l.

SYNUA DOOR

SYNUA DOOR

The safety door for large dimensions, with vertical pivot operation and installation coplanar with the wall.

Synua is the safety door that knows no limits: ideal for large sizes, it is the perfect combination of technology and design.

Equipped with pivoting opening, and coplanar with the wall, it is covered by sectors or by a single panel or by a solution upon customer drawing, and can reach up to 3000 mm of width and 6200 mm of height in its standard versions. Upon request it can feature even larger dimensions.

INFORMATION

FREEDOM IN TERMS OF SIZE

Synua, the safety door with vertical pivot, allows a wide freedom in terms of sizes, ideal for large entrances, designed to follow the trends of contemporary living.

AUTOMATIC OPENING WITH FLOOR MOTOR

Electronics components are designed to allow for maximum refinement of movement, conceived mainly for large pivoting doors. Management system configurable with the Oikos Arckey App.

SYNUA WALL SYSTEM

The Synua Wall System exploits the perfect coplanarity of Oikos doors in order to create walls that share the same aesthetic concept. Consisting of modular sectors that can be covered with different materials, SWS creates spectacular wall systems. A wall-door that combines the scenic and aesthetic effect with safety, elegance, and protection.

OWNER'S KEYS BOX

All Oikos safety doors are supplied with a building site key to be used for production checks and by technicians entrusted with installation tasks. The owner's keys, on the other hand, are always supplied sealed inside a special elegant box.

PIVOTING OPENING OF THE DOOR

The opening and closing of the door take place by means of a vertical pivot, i.e. two pins placed at the ends, which are adjustable and concealed. The leaf, by turning on itself, allows a wider opening and greater brightness.

SHAPES

Synua is available in the two versions with single leaf or with side panel.

SAFETY DOOR WITH PIVOT HINGES WITH

- Maximum feasible size: 3000x6200mm (greater on request)
- Covering with sectors, single panel or upon customer design
- Version with heat barrier frame and leaf (optional)
- Motorized electronic lock with integrated access control system on request
- Automatic opening with floor motor for doors weighing up to 560 kg on request

COVERINGS

- Line Piano
- Line Fugato
- Line in sectors
- Custom
- Skydoors

SPECIFICATIONS

PERFORMANCE	STANDARD	UPON REQUEST
Break-In Resistance	Class 3	-
Thermal	1.6	1.3
Acoustic	38dB	-
Air	2	Mose Kit 4
Water	0	Mose Kit 5A
Wind	C4	Mose Kit C5
Fire	-	EI 60 / VKF 60 / EI 120 / UL-FD 120
Hurricaneproof	-	Hurricaneproof Noa

FEATURES

ARCKEY SYSTEM

The Oikos Arckey App is the integrated access management system that allows the electronic opening directly from a smartphone. The opening of the door with remote button, the user management, and the control of access flows are just some of the functions allowed by the management through App. The Arckey App can be downloaded for free from the App Store (iOS) or from Google Play (Android).

CARD READER

The Arckey system foresees, as a complementary system to the door opening, the use of the Oikos Card to be placed directly next to the leaf.

TOUCHPAD

The leaf opening can take place by entering a code on a touch screen support.

FINGERPRINT READER

Opening the entrance can be done simply through fingerprint recognition. Integrated in the door and minimal in terms of aesthetics and functionality, the fingerprint reader does not require keys or magnetic cards but only the use of the finger.

SMARTPHONE

Door opening via smartphone and manageable through the Oikos Tech App.

LONG HANDLE ORIZZONTE MODEL

The Skydoors long handle houses door-opening accessories. The glass support embellishes the hi-tech housings making them real jewels.

LONG HANDLE DIRETTRICE MODEL

The long handle is an integral part of the door design, harmonizing with the vertical slats but not losing its own identity while maintaining the character of an accessory that ennobles the door.

TEKNO - SWS BOISERIE

The Synua Wall System exploits the perfect coplanarity of Oikos doors in order to create walls that share the same aesthetic concept. Consisting of modular sectors that can be covered with different materials, SWS creates spectacular wall systems. A wall-door that combines the scenic and aesthetic effect with safety, elegance, and protection.

TEKNO - FIRE RESISTANCE

On request, it is possible to install the E16, EI 120 fire-barrier according to EU standards. The Tekno UL 120 door, certified by the UL laboratory, is instead a guarantee of compliance with the rigorous U.S. standards for the manufacture of doors that can withstand fire for 120 minutes.

TEKNO HURRICANE PROOF CERTIFICATION

The Miami Dade-certified Tekno door, issued by the County of Miami, ensures that it meets stringent quality standards in door designs that can withstand extreme wind loads caused by hurricanes.

TEKNO - FREE FAÇADE

Oikos proposes "free façade", a new architectural solution in which the safety door is inserted in a seamless wall for a perfect integration of the leaf with the overall finishes. No visible opening elements, motorized opening and access via the Oikos Tech App. Free Façade has officially become part the ADI Design Index 2016

STANDARD DRAUGHT EXCLUDER

A floor device that, when the door is closed, correctly insulates a room from cold air draughts, smoke, dust and noise, contributes to greater living comfort and also guarantees savings in the energy needed for air conditioning. The draught excluder perfectly closes the gap between the leaf and the floor.

SOLUTION WITH MOSE KIT

The use of the Mose threshold is necessary when you want to obtain maximum performance and the installation site features a non-homogeneous floor.

SOLUTION WITH DAM KIT

The ultimate solution in terms of invisible threshold performance! The Dam kit allows a high isolation from external agents totally eliminating architectural barriers. Solution installable only when there is a homogeneous plan.
