EXPOSED BR7-35 PROFILE A ROOF SYSTEMS
EXPOSED BR7-35 PROFILE A ROOF SYSTEMS
Exposed fastener panels are easy to install, economical, and versatile. Profile A and B may both be used for wall systems. Profile A is designed for roof systems as the high cell lap promotes proper drainage.
information
CHARACTERISTICS
Exposed fasteners, low cell lap, wide range of profile options, customizable finish
USE
Exterior cladding
SYSTEM
Roofing System
MATERIAL
Available in Heavy Gauge Galvalume, Aluminum, Zinc, Stainless Steel, and Copper.
CERTIFICATION AND TESTING
- Air Infiltration : ASTM E283
- Water Penetration : ASTM E331
PANEL ATTACHMENT
Exposed through-fasteners (color matched fasteners available)
ALUMINUM OPTIONS
.050/ .040 / .032
ZINC OPTIONS
1.0 mm / 0.8 mm
INSTALL APPLICATION
- Wall
- Roof
- Perforated screen
- Horizontal
- Vertical
CHARACTERISTICS
- Exposed Fasteners
- Low Cell Lap
- Wide Range of Profile Options
- Customizable Finish
NATURAL COPPER OPTIONS
20 oz. / 16 oz.
STAINLESS STEEL OPTIONS
20 ga / 22 ga / 24 ga
SIZE
- Length : 5' mm to 30' mm
- Depth : 1⁄2” (3mm) - 4"mm
- Cover Width : 24”-40" (711mm)
FORMAT
Horizontal / Vertical
BRAND
Morin Corp
DETAIL
Exposed fastener panels feature bold profiles with varying widths and depths to suit any structural and architectural design requirements.
USED
May be used for roof, wall, or perforated screens
CORNERS
Mitered seam corners and curving options
OPTIONS
Standard and custom perforated options
COLORS
Color matched fasteners available
EASY
Exposed Fastener Design For Easy Install
PANEL DIMENSIONS
- Width: 35" nominal
- Depth: 1.5" nominal
- Standard Lengths: 5'-30' (shorter and longer lengths available)
COLOR AND FINISH OPTIONS
Full range of Morin standard colors as well as custom color options are available. Finish on one side or both sides
MACHINE
Machine roll formed for top quality consistent product
GALVALUME/ZINCALUME PAINTED STEEL OPTIONS
18 ga / 20 ga / 22 ga / 24 ga
