Aurubis Nordic Brass Panels
NORDIC BRASS PANELS
NORDIC BRASS PANELS
Nordic Brass is an alloy of copper and zinc with a distinctive golden yellow color.
INFORMATION
USE
Copper Surfaces
APPLICATIONS
Roofs and Façades
FABRICATION PROPERTIES
- Formability : Excellent
- Soldering : Excellent
- Brazing : Excellent
- TIG : Good
- MIG : Good
- EBW : Poor
LENGTH
- Nordic Brass : Unlimited
- Nordic Brass Weathered : 1,000
CHEMICAL COMPOSITION %
- Copper (Cu) : 84/ 86
- Zinc(Zn) : 14/ 16
COILS
Maximum 3500 kg
DOWNLOAD
↓ Specification Sheet
BRAND
Aurubis
PRODUCT TYPE
Metal Panel Facades
MAXIMUM WIDTH
1.000 mm
THERMAL CONDUCTIVITY
160 % W/Cm
NORDIC BRASS – ALLOY
Nordic Brass is an alloy of copper and zinc with a distinctive golden yellow color.
THICKNESS RANGE
- Nordic Brass : 0.5 — 2 mm
- Nordic Brass Weathered : 0.5 — 1.5 mm
DELIVERY FORMS
- Sheet
- Coil
SHEET LENGTH
Maximum 6000 mm
SPECIFIC HEAT
375 J/kg K
CHARACTERISTICS
- Custom Finishes And Forms Available
- Instant Patina Created
- Natural Patina Can Continue To Form After Installation
- Planning And Installation Support
NATURALLY EVOLVING COPPER
Ongoing changes will continue over time with all Nordic Products depending on the local environment. As a result, when exposed to the atmosphere, the surface begins to darken within weeks and can change to a dark brown in around a year.
NORDIC BRASS WEATHERED – PRE-OXIDISED BRASS
Nordic Brass Weathered material is burnished at the Aurubis mill to immediately provide the same oxidised brown surface that otherwise develops over time in the environment.
COMBINATIONS FOR VISUAL EFFECTS
Nordic Brass can also be combined with other surface finishes such as Nordic Green to create various visual effects.
FINISHES
