Fakro FP_-V PreSelect Pivot Roof Window
FP_-V PRESELECT PIVOT ROOF WINDOW
FP_-V PRESELECT PIVOT ROOF WINDOW
Top hung and pivot window preSelect MAX
The sash in the FPP-V preSelect MAX top hung and pivot window can be opened up to 45°, which is nearly 30% more than when compared to the previous model.
This significant improvement allows for better use of the additional space created within the room. Thanks to two independent opening mechanisms, the innovative hardware system guarantees the complete stability of the sash in both opening functions. This provides high durability of the product and safe operation.
- Wide range of additional accessories.
- Suitable for pitches from 15-55°, in a special version between 55-85°.
- Handle ‘Elegant” positioned in the base of the sash for easy operation and two step micro-opening.
- The pivot function enables the sash to be rotated through 180° and locked when cleaning the outer pane or installing the awning blind.
FEATURES
TWO OPENING OPTIONS
The preSelect MAX window comes with two independent opening mechanisms to ensure stability and increase safety of operation. The sash can be opened outwards from the top and via centre pivot. The innovative hardware system guarantees the complete stability of the sash in both opening functions. The outward opening option provides an additional space within the attic and panoramic views of the outside. In pivot mode the sash can be locked into position to facilitate cleaning of the outer glass.
PRESELECT MAX SWITCH
The preSelect sliding switch in the new FPP-V window is placed in the bottom part of the frame for improved comfort and operation. The switch is used for choosing opening method and is invisible when the window is fully closed
LARGE SIZES
Windows are available with the U3 glazing unit as standard. Their design allows to produce large-sized windows, including triple-glazed ones. Windows come in sizes from 78×160 (with the U5 glazing unit) and in sizes from 94×118 (with the U3 glazing unit) and in sizes 114×160, 134×118 and 134×140.
AUTOMATIC V40P AIR INLET
The V40P air inlet automatically adjusts the air flow channel to provide an optimum amount of air into the room. This also gives a healthy micro-climate, energy savings and reduced heating costs.
TOPSAFE SYSTEM
A number of unique features known from the previous model have been incorporated into the new preSelect MAX window such as the topSafe anti burglary system which stands behind enhanced safety and security as well as burglary resistance.
THERMOPRO TECHNOLOGY
The solutions introduced ensure improved quality and parameters of roof windows, thus increasing their energy-efficiency performance, providing greater durability, ensuring excellent tightness.
INFORMATION
BRAND
Fakro
USE
Roof windows
HANDLE
Elegant
GLAZING UNIT
4H-16-4T
DOWNLOADS
↓ User Manuals
↓ Fitting Instructions
CHARACTERISTICS
Top hung and pivot windows, two independent opening mechanisms, the sash can be opened outwards from the top and centre pivot, suitable for pitches from 15°-55° (special version 15°-85°)
GLAZING U-VALUE
1.0 W/m²K
WINDOW U-VALUE
1.3 W/m²K
INERT GAS FILLED PANES
Argon
ACOUSTIC INSULATION RW
32 dB
AIR INLET TYPE
V40P
EXTERNAL GLASS TOUGHENED
Plus (+)
GUARANTEE
Lifetime against hail, 10 years for windows, 20 years for glazing unit
APPLICATIONS
- Loft
- Attic
- Residential
- Interior design
SEALS
Four
VARNISHING
Triple
FPP-V PRESELECT MAX
- Automatic air inlet V40P
- Highest quality pine wood, glued in layers, vacuum impregnated
- Wood painted twice with ecological acrylic lacquer in natural colour
FPU-V PRESELECT MAX
-Automatic air inlet V40P -Highest quality pine wood, glued in layers, vacuum impregnated -With three coats of polyurethane varnish ideal for creating a durable and smooth finish in white on the frame surface -Designed for rooms with periodically elevated humidity levels (kitchens, bathrooms)
