Americanpoleandtimber Piling Repair Snap Jacket
PILING REPAIR SNAP JACKET
PILING REPAIR SNAP JACKET
Snap Jacket Piling Repair And Protection Sleeves/ Low Cost, Long-Lasting Wood Piling Repair
Repair your rotted pilings quickly and inexpensively with the SnapJacket.
Even broken pilings repaired with SnapJacket are stronger than before. Plus, SnapJacket’s design makes it very easy to install, keeping timber pilings repair costs to a minimum.
Installing on existing pilings even broken pilings means you save Thousands of dollars because you don't have to pull old pilings, buy new ones, or pay for piling installation.
INFORMATION
BRAND
Americanpoleandtimber
PRODUCTION
Made in USA
MATERIAL
PVC Plastic
USE
Piling Repair Sleeve
APPLICATIONS
- Marine Piling
- Submerged Piling
DIAMETER
10, 12, 14, and 16-inches
PROPERTIES
- UV Protection
- Synthetic
CHARACTERISTICS
-UV Resistant -PVC Exterior -Concrete Infill -Retrofit Installation -Economic Solution -Extremely Durable
SNAP JACKET PILING REPAIR JACKET FOR WOOD PILINGS
Repair, protect, and beautify pilings with SnapJacket vinyl piling jackets. The UV-resistant vinyl jackets are the longest-lasting and most cost-effective option for repairing or extending the life of wood pilings in water.
RETROFIT
By opening up and easily locking back together, using the SnapJacket does not require you to disassemble any portion of the structure built on top of the piles. With proper engineering the SnapJacket can even restore a completely broken & rotted pilings to beyond its original strength.
25 YEAR WARRANTY
Due to the fact that PVC does not wear down in the water, we offer a 25-year warranty on the Snap Jacket. The concrete will remain untouched by the elements, effectively fossilizing everything inside of the jacket. Theoretically, this rotted pilings repair jacket should last a lifetime and then some.
AVAILABLE UP TO 16 INCHES
Available in 10, 12, 14, and 16-inch diameters, the Snap Jacket will fit around most marine piles. It is recommend you choose a piling repair jacket that has at least an inch and a half of annular space all the way around the pile.
EASY TO INSTALL
-Simply cut the jacket to length, blow out the sand and slip it around the pile without disturbing any of the deck above. -Slide the locking device down the middle and your form is ready to fill. -Lastly, pour the void with concrete, the concrete will then flow into the voids creating a new solid piling.
Once the jacket is filled with cement, all marine boring organisms that are eating away the inside are instantly killed. From then on the pilings will be protected from any future environmental and organism damage.
GALLERY
