MOSCONE CENTER-WALLSCREEN
We leverage extensive experience across optimized manufacturing practices and value engineering. At BŌK Modern, we help you figure out the details to champion your design vision, understanding architectural intent and the sequencing of construction.
EnFold Façade Wallscreen systems are applicable to building exteri-
ors, parking garage screens, and green screens as well as a variety
of interior room divider, wall and ceiling applications. EnFold Façade
panels can be directly mounted to edge of slab or other structure
without the need for secondary supporting members. Panel systems
are delivered to site fully fabricated and finished, ready for immediate
Installation. Designed with the same precision laser cutting typical
throughout the entire BŌK Modern line of products, EnFold Façade
Wallscreens can encompass an infinite array of patterns and shapes,
and be finished in Kynar, powder coat, anodized aluminum, or rusted
surface (Core-ten) steel.
information
BRAND
BŌK Modern
ELEVATION DETAIL
Wall/green screen panel
MATERIAL
Aluminium
DOWNLOADS
↓ PDF file
FINISHES
- Powder Coat
- Kynar
- Anodized
- Unfinished
SHEET MATERIAL
- 5052-H32 AL
- Astm A242 Cor-ten
APPLICATIONS
- Exteriors
- Cultural Center/Commercial
SECTION DETAIL
Wall/green screen panel
BRACKET CONNECTION
Horizontal section
USE
Screening systems for lateral support, self-reinforcing structure, custom-staggered to building conditions
SHEET THICKNESS
1/8, 3/16", 14 GA, 12 GA
MAX PANEL HEIGHT
10 ,13', 9' - 6", 12'
CHARACTERISTICS
- Patterns
- Lightweight
- Materials, 3D
- Customizable finishes
OTHER INFORMATION
Wall/green screen panels can be mounted in a modular configuration using standard knifeblade support brackets.
- Standard and custom patterns.
- Interior and exterior applications.
- Bracket plate can be concealed behind finish
DIMENSIONS
- Depth : 2"
- Width : 4' - 0"
WHY ENFOLD FACADE?
EnFold Façade, a division of BŌK Modern, offers both a patented
Rainscreen system as well as a Wallscreen system. Both are de-
signed to minimize on-site labor by integrating features directly
into the panels to accelerate installation times resulting in reduced
overall installed costs.
EnFold Façade panels can be fabricated from a variety of flat sheet metal materials that are strategically designed and cut by laser with a virtually infinite array of patterns and shapes.
Structural rigidity is in- tegrated directly into panels through specialized and precise forming, eliminating the need for welding or secondary structural elements. The EnFold Façade system incorporates tabs and slots to control spacing and ensure quick and easy installation. When installed over a suitable substrate, our direct mount unitized panel system generally requires no additional furring or secondary support members.
