Ottostumm Bronzo Finestra B75 TB Window System

Tue Dec 06, 2022Steel Structure Hardwares, WindowsConstructionGlass, Steel, Bronze

BRONZOFINESTRA B75 TB WINDOW SYSTEM

BRONZOFINESTRA B75 TB WINDOW SYSTEM

Architectural Bronze

The elegant and sleek lines of FerroFinestra W75 TB are also available in exclusive architectural bronze and run under the system name BronzoFinestra B75 TB.

This noble profile system was developed for projects with highest prestige demands. With its limitless surface shades, architectural bronze is a living material that gives windows and doors an undisputed charm.

The profile depth of 75 mm allows to accommodate highly energy-efficient insulating glazing up to 52 mm and the fiberglass-reinforced polyamide insulator guarantees excellent thermal insulation, making the system ideal for projects in climatically demanding regions, where energy-saving regulations are extremely high.

The assortment is rounded off by a wide range of exclusive fittings and accessories reproduced from original designs of the modern age.

This allows the realization of all common opening types (inside and outside opening) for windows and doors, including tilt and turn windows. The system is available with a flush or overlapping design.

INFORMATION

APPLICATIONS

- 19th/20th-century Renovation
- Residential
- Commercial
- Institutional

BRAND

Ottostumm

PRODUCT TYPE

Window System

PRODUCTION

Made in Switzerland

COLLECTION

Bronzo Finestra

USE

Exterior fenestration systems

SHADES

Natural finish, or burnished in different shades

DIMENSIONS

- Height : 82 cm
- Width : 49 cm

CHARACTERISTICS

- Corrosion Resistant
- Welder Friendly
- Suitable For Large Glazing
- Multi-purpose System
- Thermally Insulated
All Common Opening Types Available

HARDWARE

Visible and concealed

CERTIFICATION

Recognized By Green Guide

FEATURES OF MLS72 TB

-Solid extruded profiles -Mechanically fixed rebate gaskets -Very slender flush or overlapping sightlines -Profiles accommodate high-performance glazing -High performance thermal barrier -Wide range of square and angular glazing beads -Fixed glazing, single-sash and double-sash, side-hung and bottom-hung windows opening inwards and outwards, top-hung, tilt and turn windows, vertical and horizontal pivoting windows, window and doors opening inwards and outwards
