LAGO METAL FABRICS
LAGO METAL FABRICS SUNSHADING FAÇADES
GKD-USA offers a complete sunshade technical program. Our engineering team works with you to provide an assessment and application analysis to your specific need or project.
GKD Metal Fabric Sunshading Façades offer significant energy saving, comfort, and a pleasant work environment by filtering light and providing transparent views to the outside.
INFORMATION
MATERIAL
AISI Type 316 SS
OPEN AREA
44%
WEIGHT
1.50 lbs/sqft
PRODUCTION
Made in USA
APPLICATIONS
- Solar Mesh
- SteelWeave?
- Facades
- Suspended Metal Mesh Ceiling Panels
- Safety and Security
- Partitions
TYPE
- Flexible
- One direction
DIMENSION
Max. Width : 26'
VISIBLE LIGHT REFLECTANCE
- Minmum : 0.16
- Maximum : 0.24
VISIBLE LIGHT TRANSMITTANCE
- Minmum : 0.15
- Maximum : 0.51
SYSTEM COMPONENTS
- Flat & angle
- Flats with clevis
- Frame
- StealthLok & StealthLok Sprung
- U-binding frame
- WIB - hooks and springs & hooks and eyebolts
- WIB - eyebolts top and bottom
SOLAR CONTROL DATA
- Percentage of Visible Light Transmittance : Minimum 0.15, Maximum 0.51
- Percentage of Visible Light Reflectance : Minimum 0.16, Maximum 0.24
- Solar Gain Coefficient (SHGC) : Minimum 0.14, Maximum 0.37
