Ottostumm Ferrofinestra W65 Window System
FERROFINESTRA W65 WINDOW SYSTEM
FERROFINESTRA W65 SECURITY WINDOW SYSTEM
Steel
Mogs M65 profiles are made from 2 mm cold-formed zinc-magnesium steel, which grant a high internal and external protection against rust and atmospheric corrosion.
This system is an ideal solution for large glazing in milder climatic zones and with its 65/72 mm profile depth an extremely strong framing material for security windows.
Mogs M65 was developed as a multi-purpose system and profiles used for fixed frames or outer casement frames can be used as well for window vents, keeping the assembly fast and simple.
With only 5 different profiles a large variety of windows, including tilt and turn windows, and doors can be manufactured.
information
BRAND
Ottostumm
PRODUCT TYPE
Window System
MOMENTS OF INERTIA
2 mm tubular profile with high moments of inertia
BEADS
Wide range of square and angular glazing beads
MATERIAL
- Galvanized Steel
- Cor-Ten Steel
- Stainless Steel
- Bright Steel
GASKETS
-Mechanically fixed rebate gaskets -Optional kit for center gaskets
ANY KIND OF OPENINGS
-Side-hung -Top-hung and bottom-hung windows -Tilt and turn -Pivoting and folding doors.
PRODUCTION
Made in Italy
COLLECTION
Ferrofinestra
USE
Interior Partitions
CERTIFICATION
Recognized by Green Guide
PERFORMANCE
Continuously welded profile, high mechanical performance
ACCESSORIES
-Wide range of accessories with visible -Concealed hinges
W 65 SECTIONS
- Section 1
- Section 2
- Section 3
- Section 4
CHARACTERISTICS
- Choice of type and finish
- High stability profiles
- Can span large areas
- Natural surface finishes
HINGS
Wide choice of specific fittings, including both visible and conceived hinges
GLAZING
- Triple glazing
- Accommodate double
Choice of different glazing beads
POLYAMIDE
Thermal barrier in pa 6.6 polyamide
OVERLAPPING SIGHTLINES
- External flush
- Internal overlapping sightlines
COMPATIBLE
Profile depth compatible with high performance insulating glass
APPLICATIONS
- Residential
- Commercial
- Institutional
- 19th/20th-century renovation
W 65 PROFILE RANGE
GLAZING BEADS GASKETS AND ACCESSORIES
HUNG
-Fixed glazing, tilt and turn, single-sash and double-sash -Side-hung and bottom-hung windows opening inwards and outwards -Top-hung, vertical and horizontal pivoting windows -Window and doors opening inwards and outwards
