Moga Ferro Finestra W40
FERRO FINESTRA W40
FERRO FINESTRA W40
Hot rolled steel
The W40 range is an evolution of the famous W20 range developed in 1964. Produced for the first time in 1995 it consists of 17 hot rolled profiles and follows the unmistakable classic design of its predecessor.
The strong point of this “younger” series is the increased profile depth, which allows accommodating double-glazing up to a thickness of 27mm.
The W40 suite proposed by OTTOSTUMM is not only used in the field of restoration, but it’s also highly acclaimed in contemporary architecture for its elegant and compact sightlines, ensuring safety and comfort thanks to its excellent thermal and acoustic performance.
Despite the depth of this system is only of 42 respectively 47 mm, technically it is considered a “heavy duty” range, which allows making tall and expansive windows.
information
USE
Interior partitions
CERTIFICATION
Recognized by Green Guide
GASKETS
Self-adhesive non-shrinking gaskets
BEADS
Choice of different glazing beads
HUNG
-Fixed Glazing -Single-sash And Double-sash -Side-hung And Bottom-hung Windows Opening Inwards And Outwards -Top-hung -Vertical And Horizontal Pivoting Windows -Window And Doors Opening Inwards And Outwards
TECHNICAL DRAWING
DESIGN
Classic “Stepped leg” design
THICKNESS
Material thickness up to 5 mm
FITTING
Compatible with tilt-turn fittings
ROLLED
Solid hot rolled steel profiles
GLAZING
Accommodates low emissivity double-glazing up to 27 mm
APPLICATIONS
- 19th/20th-century renovation
- Residential
- Commercial
- Institutional
CHARACTERISTICS
- Choice of type and finish
- High stability profiles
- Can span large areas
- Natural surface finishes
SECTIONAL DRAWINGS
W 40 SECTIONS
GLAZING BEADS GASKETS AND ACCESSORIES
W40 PROFILE RANGE
