Uponor Siccuss SW For Wall Stud Installation
SICCUSS SW FOR WALL STUD INSTALLATION
SICCUSS SW FOR WALL STUD INSTALLATION
Uponor Siccus SW (stand wall) system has been developed for installation in dry wall construction. It consists of a solid alumimium support element with integrated omega-shaped pipe grids.
The elements are already pre-assembled in dimension 14x2 mm using high-pressure cross-linked Uponor PE-Xa pipe. Proper pipe connection have been considered for an efficient assembly process.
One man installation can be carried out as the elements only weight 2.4 kg per piece. The system is easy and quick to install using standardized distance between the panels. Heat is delivered where it is needed as the pipes are laid close to the surface.
INFORMATION
CONSTRUCTION
Dry Wall
BRAND
Uponor
MATERIAL
Alumimium
CHARACTERISTICS
- Energy-efficiency
- Sustainable
USE
- Solutions For Plumbing
- Radiant Heating and Cooling
- Local Heat Distribution
PRODUCT TYPE
Steel Frames
PRODUCTION
Made in Italy
APPLICATIONS
Hotels
TYPE
Wall Stud
ADVANTAGES
- Retrofit installed stud walls will get efficient heating and cooling surfaces
- Light weight and handy dimensions of panels for one-man installation
- Standard spacing of 625 mm
- Can be used for heating and cooling in new build as well as for renovation
