Kasso Expanded Mesh Metal
EXPANDED MESH METAL
EXPANDED MESH METAL
KASSO Expanded Metal is economic, durable, sustainable- whether as a building envelope, interior or ceiling cladding, sun or privacy protection- and available both for architectural and industrial applications. .
The openings in the material allow flow through of air, water, and light, while still providing a screen
Expanded mesh metals can be made according to standard or specific measurements and are available both in sheets and coils.
Expanded mesh is available in a variety of forms, sizes, thicknesses, transparency to suit project design requirements. Apart from the existing molds, there is the opportunity to develop project-specific molds and products.
INFORMATION
MATERIAL
Metal
PRODUCT TYPE
Steel Frames
APPLICATIONS
- Residential
- Commercial
- Industrial
- Education
- Renovation projects
CATEGORY
Expanded Mesh
PRODUCTION
Made in Turkey
FEATURED FRAME DETAIL
KASSO Panels are available as flat, bended or framed as per project’s requirement. A principal detail is shown in this section, panelling and structural details can be customised and supplied as ready to install with patented framing systems.
BRAND
Kasso
DOWNLOAD
↓ Materials & Surfaces Sheet
CHARACTERISTICS
- Aesthetic
- Durable
- Stable
- Customisable
USE
- Railings
- Fences
- Exterior or interior staircase
- Gallery or balcony balustrades
MATERIALS & SURFACES
Each surface design gives every building its individual character. KASSO panels are available in a large variety of finishes and materials, which provides designers and architects the freedom to create a diverse range of patterns and designs.
EXPANDED MESH OPTIONS
SKY GM126 ( MICROMESH METAL )
- Size 12,00x6,00x1,50x2,00mm
- Open Area Ratio (%): 50
FIT GM64 ( MICROMESH METAL )
- Size 6,00x4,00x1,00x0,50mm
- Open Area Ratio (%): 50
FEEL GM168 ( MICROMESH METAL )
- Size 16,00x8,00x2,00x1,5,00mm
- Open Area Ratio (%) 50
SMART GM3010
( DIAMOND EXPANDED MESH )
- 30,00x10,00x3,00x2,00mm
- Open Area Ratio (%): 50
BASIC GM7525
( DIAMOND EXPANDED MESH)
- 75,00x25,00x6,00x2,00mm
- Open Area Ratio (%): 50
STYLE GM11550
( DIAMOND EXPANDED MESH )
- 115,00x50,00x12,00x3,00mm
- Open Area Ratio (%): 50
HONEYCOMB GM4520
(HEXAGONAL EXPANDED MESH )
- 45,00x20,00x3,00x2,00mm
- Open Area Ratio (%): 65
JOINT GM5020
( HEXAGONAL EXPANDED MESH )
- 50,00x20,00x3,00x2,00mm
- Open Area Ratio (%): 70
TREND GM10050
(HEXAGONAL EXPANDED MESH )
- 100,00x50,00x12,00x2,00mm
- Open Area Ratio (%): 45
ARMY GM16060
(BIG EXPANDED MESH )
- 160,00x60,00x13,00x3,00mm
- Open Area Ratio (%): 65
XXL GM20080
(BIG EXPANDED MESH )
- 200,00x80,00x20,00x3,00mm
- Open Area Ratio (%): 50
GRAND GM250100
(BIG EXPANDED MESH )
- 250,00x100,00x25,00x3,00mm
- Open Area Ratio (%): 50
SHARP GMS11525
(CUSTOM EXPANDED MESH)
- 115,00x25,00x11,00x2,00mm
- Open Area Ratio (%): 37
WAVE GMS10016
(CUSTOM EXPANDED MESH )
- 100,00x16,00x7,00x2,00mm
- Open Area Ratio (%): 39
DELICATE GMS7512
(CUSTOM EXPANDED MESH )
- 75,00x12,00x6,00x2,00mm
- Open Area Ratio (%): 33
GLOBE GM2012 ( ROUND EXPANDED MESH )
- Size 20,00x12,00x3,00x1,00mm
- Open Area Ratio (%): 68
BIRD EYE GM4025 ( ROUND EXPANDED MESH )
- Size40,00x25,00x4,00x2,00mm
- Open Area Ratio (%): 50
