BETTEART BATHTUB
BETTEART BATHTUB
As if shaped in a single piece, the BetteArt is a free-standing bath in its purest form. The exterior and interior bath bodies are smoothly joined with the greatest skill and craftsmanship to extremely narrow side walls.
The result is an object of the greatest symmetry and soft lines that fills any room with a special aura. The bath is fitted with the specially development BetteArt waste and overflow system, and is also available in a wall-mounted version.
information
FUNCTIONS
2-seater bath, Bath with apron
SHAPE
Oval
CAPACITY
248 l
INSTALLATION TYPE
Free-standing
DIMENSIONS
- Length : 805 mm
- Width : 755 mm
- Depth : 420 mm
LYING DIMENSION
1564 mm
EDGE HEIGHT
560 mm
SCOPE OF DELIVERY
Including noise-reducing sound-dampening pads.
DRAIN DIAMETER
52 mm
WEIGHT
113 kg
ITEM NUMBER
3480 CFXXK
BRAND
My-bette
TECHNICAL ADVICE
The special waste- and overflow fitting BetteArt is compulsory for installation. The BetteArt waste-and overflow comes prefitted. If ordered with waste and overflow with filling unit the bath comes with prefitted Sanfix tube for water supply. A flexible drain pipe is included in delivery.
TECHNICAL DRAWINGS
COLORS
GLOSSY COLORS
-White (000) -Black(053) -Natura(038) -Pergamon(001) -Manhattan(002) -Bahamabeige(003) -Starwhite(287) -Midnight(790)
MATT COLOURS
-Snow(440) -Blue Satin(418) -Ebony(035) -Edelweib(004) -Flanell(008) -Jasmin(006)
