Terrealfacade Piterak Slim Cladding System
PITERAK SLIM CLADDING SYSTEM
PITERAK SLIM CLADDING SYSTEM
A rainscreen cladding sized to seduce
Piterak Slim is a 30mm thick, double-skin terracotta rainscreen cladding system with overlapping horizontal reveals.
The system contains a large module terracotta panel available in a variety of standard sizes and a multitude of made-to-order sizes with a maximum height of 60 cm and maximum length of 180 cm.
The system provides high wind resistance and the highest (Q4) impact resistance rating under French CSTB (an ICC Construction Product Evaluation Expert Alliance member) standards.
INFORMATION
BRAND
Terrealfacade
PRODUCTION
Made In France
CHOICE OF INSTALLATION
Horizontal or Vertical
LARGE LENGTH TERRACOTTA
Up to 180 cm
USE
Terracotta rainscreen cladding façade system
MODULE LENGTH
310 to 1810 mm
WEIGHT
48.5 kg/m2
THICKNESS
30 mm
FEATURES
-Fire resistant -High impact performance -Maintenance free and durability -Custom glazed, long-lasting, fade-resistant, flexible use
DIMENSIONS
SKINS
FINISHES
LAYING SYSTEMS
