Linvisibile Infinito 10 Vertical Pivot Door Brezza
INFINITO 10 VERTICAL PIVOT DOOR BREZZA
INFINITO 10 VERTICAL PIVOT DOOR BREZZA
The Infinito 10 Vertical Pivot Door is the new flush-to-wall pivot door by Linvisibile with 102 mm thick anodized or matt lacquered aluminium perimeter frame.
Available with and without stop, this pivot system is composed of two hidden pivots (floor and ceiling) which allow the panel to rotate up to 360°.
This pivoting door can enhance any design project. The leaf rotates on its vertical axis with a wide, bright and charming opening that gives a strong personality to any interiors.
Thanks to its sturdy perimeter frame, the panel of the Infinito 10 Vertical Pivot Door can be ordered in any finish that has a thickness from 3 to 6 mm.
It is a highly customisable product that allows applying different materials on each side and choosing the perimeter frame colour, either matt lacquered matching the panel surface or simply anodized in different colour variants.
information
CHARACTERISTICS
Flush with the wall on both sides, can rotate on itself to different degrees of opening, achieves continuity between door and wall, can be coated with almost any material (metal, stone, leather, wood)
USE
- Opening and closing systems
- Partitions
TECHNICAL DETAILS
- Possibility of installing a lock with an electrical strike plate;
- Possibility of installing high-performance closing systems, with speed calibration;
- Floor positioning template supplied as standard.
APPLICATIONS
- Residential
- Office
- Hospitality
- Retail
DIMENSIONS AND PERSONALIZATIONS
Thanks to the “made-to-measure” construction, the Infinito 10 Vertical Pivot Door is ideal for any commercial and residential solution.It can be ordered with single or double leaf in the following sizes:
-Width: 600 to 1200 mm
–Height: 1900 to 3500 mm
PERSONALIZATIONS
In the case of the panel designed for Heavy Coatings, such as marble, natural stones and granites, the Infinito 10 Vertical Pivot Door can be made in the following sizes:
-Width: 800 to 1200 mm
-Height: 1900 to 3500 mm
SHAPES AND OPENINGS
TECHNOLOGY
- Thanks to refined technology, the Linvisibile system guarantees a perfect flush mount between panel and wall and a millimetric perimeter variance. Moreover, the Infinito 10 Vertical Pivot
- Door system guarantees a fully concealed aluminium frame and that no unsightly cracking occurs. For all its products, Linvisibile offers an exclusive 10-year warranty for the aluminium frames and a 2-year warranty for the panels. All Linvisibile brand products are made entirely in Italy, with particular attention to design and all materials used.
FEATURES
Infinito 10 Vertical Pivot Door
– An Extruded Aluminium Frame, Available In The Pull Or Push Opening Models (En Aw 6060- Anticorodal Alloy 063), Ready To House Pivots And Lock. It Is Suitable For Both Masonry And Plasterboard Walls;
– A 102 Mm Thick Panel, Comprising :
- internal structure consisting of honeycomb panels;
- perimeter frame in extruded oxidized chemical natural aluminium applied along the perimeter to the panel with a fixing system with square angles;
- selected lining material with 3 to 6 mm thickness (laminate, fibreglass, methacrylate, glass, mirror, leather, ceramic, etc.), applied on each side. In the case of preparation for Heavy Coatings, the maximum coating thickness is 10 mm (marble, granite and natural stones);
- hidden rotating pivots, which can be positioned at a minimum distance of 100 mm from the jamb up to the centre of the panel for the model with stop, or for the model without stop, from a minimum of 350 mm from the jamb up to the centre of the panel.
- The Infinito 10 Vertical Pivot Door is prepared as standard for the application of thick coatings. In the Heavy Coatings version, the coatings are not included, but all hardware needed for installing and operating the door is included.
FINISHES
MIRROR
Mirrors are obtained from a glass manufacturing process which yields the traditional reflective characteristic. Mirrors are valuable elements that dded to interiors give the optical illusion of larger and more radiant spaces.
SPECIAL GLASS
The glass panels take on new features when undergoing satin finishing and chemical etching. The glass is available in a wide range of shades and can be further enhanced with the application of mesh and texture engravings that permit obtaining customized materials and products. A decorative solution that enhances with unique textures, reflections and colours.
GLASS
Elegant and bright with a matt or glossy effect. The rear-lacquered glasses are not clear, but allow obtaining different reflections and colors. It is characterized by the overlapping of two slabs within which a lacquered layer that can be ordered in any available RAL colours is sandwiched. It is particularly suitable for partitioning spaces requiring more privacy.
HEAVY COATINGS
The “Heavy Coatings” system can only be applied to 102 mm thick doors. The system consists of the preparation of panels assembled with an aluminium perimeter profile that acts as a “frame” for the application of coatings with considerable thickness and weight, such as marble, natural stone, granites, mosaic.
LEATHER
Natural product with high durability and precious aesthetic characteristics. A prestigious choice to cover surfaces with original textures that yield tactile sensations, strength and elegance. A material synonymous with Made-in-Italy excellence in a product that guarantees maximum customisation and meticulous attention to every detail.
ANODISATION
The anodized aluminum frame is available in four standard fine-grained brushed colors, with a choice of warm and cool shades. Other coarse brushed or matt polished colors are available upon request. This treatment, by which the metal surface is coated with a protective oxide layer, protects the frame from corrosion, also giving it unique aesthetic properties.
METAL
Surface shine, of metal. Amazing finishes that can be applied on all doors, available for the designer to give form to a space that reflects his/her imagination. Metal plates to choose between copper, brass and aluminium, of a variable thickness in function of the required finishing, applied to the facades oh the honeycombe panel by glueing.
CERAMIC
It is a product characterized by eclecticism and versatility, with multiple applications in traditional and out-of-the-box architecture, furnishing and design. Linvisibile has chosen the ceramics of leading companies in the production of ceramic slabs, whose creations can combine large sizes and lightness with great sturdiness. Sophisticated processing technologies guarantee the inalterability of the characteristics and chromatic properties of the slabs, which remain unchanged over time, even if exposed to the elements.
LAMINATE
A new generation of smart materials for the typical vertical and horizontal applications found in interior design. The laminates we have chosen for our products have unique features. Thanks to the innovative processing they undergo, they are moulded with fingerprint-proof surfaces, soft to the touch, matt and extremely resistant, so as to withstand bumps and scratches, as well as any possible damage from solvents and reagents typically used in household cleaning products. For the laminated finish, we relied on the collections by three cutting-edge brands, such as Fenix®, Homapal® and Formica®, which offer maximum quality and a wide range of colours.
FABRIC
An inimitable material that enhances the beauty of the panels, yielding an extraordinary tactile experience. Manufactured with cutting-edge technological processes, the fabric guarantees unique aesthetic, technical and sensorial performances. Fabric offers at once elegant and refined yet light, sturdy and durable solutions. For this finish, we have entrusted Alcantara®, which embodies the new paradigm of contemporary lifestyle sought after by those who look for functionality and the emotion of beauty, while also respecting ethics and the environment.
MICROCEMENT
The panel with MDF base is prepared in a lowered position to accommodate the application of micro-cements (not supplied) of up to 8/10 mm thick, so as to allow precise shaving bordered by the outer frame. This makes it possible to compensate for any curving effects due to the dynamics inherent to the material. Two types of micro-cements can be applied: “thick” (with laminate linings of 9 mm) or “thin” (with MDF linings of 2.3 mm). Maximum applicable weight 40 kg.
