ACOUSTIC SYSTEM FOR WALLS & CEILINGS
ACOUSTIC SYSTEM FOR WALLS & CEILINGS
FabriTRAK® established itself early on by creating a framework, known as 'trak', that is manufactured from a unique blend of polymers and fire-retardant additives tested to virtually no VOC emissions.
The FabriTRAK® System incorporates over 50 profiles of wall and ceiling trak, infill and fabric, and is designed to reduce Hertz levels (noise), enhance speech clarity and privacy, and provide an excellent articulation index, all while allowing designers total creativity in an interior space.
All FabriTRAK® Systems are constructed and installed on site by professional installers, ensuring precise panel alignment and an exact fit.
FabriTRAK® is never pre-fabricated and design changes may be made at the time of installation - creating a completely customized sound solution.
Information
FORMAT
- Customized Trak
- Infill And Fabric Stretch Wall
- Ceiling System
FABRITRAK® PROFILES
- Bevel
- Available In Square
- Radius & Corner Edges
COLORS
- Natural
- Black
CERTIFICATION
- Fabritrak – Class A Fire Rating
- Infill – Acoustic Testing To C423/e795 And Class A Fire Rating
- Terracore® Poly – Leed V.4
- Declare Label
- Astm E84 Class A And .85 Nrc (Composite System Value)
APPLICATIONS
- Commercial
- Hospitality
- High-end Residential
- Cultural And Religious Spaces
- Educational And Sports Facilities
SIZE
- 3/8" (10 mm)
- 1/2" (13 mm)
- 3/4" (19 mm)
- 1" (25 mm)
- 1 1/4" (32 mm)
- 2" (50 mm) sizes
- FabriTRAK® ceiling profiles are available in 1 3/8" (35 mm).
CHARACTERISTICS
- Acoustic Performance
- Interior Finish
- Fire Retardant
- Virtually No Voc Emissions
- Custom Built On Site
- Over 50 Trak Profiles
- Choice Of Infill And Finish
USE
- Interior Wall
- Ceiling Finish
DOWNLOADS
↓ Data Sheet
↓ FabriTRAK® Systems
FIRE TESTS
All FabriTRAK® profiles in size ranges from 3/8" to 2" have been tested in accordance with ASTM E84-08 and later editions and have achieved a Class A rating. -A more complete and detailed explanation of fire testing methods and their incorporation into fire and building codes, along with FabriTRAK's compliance can be obtained by contacting us directly.
CODE CLASSIFICATION SYSTEM
| System Size | Furring | Fabric | System | Infill | Flame Spread | Smoke Development | Midseam |
|---|---|---|---|---|---|---|---|
| 3/8" | None | 13984 – Guilford of Maine – FR701 | FabriTRAK® System | FabriFill (Double Layer) | 25 | 200 | Yes |
| 3/8" | None | 12904 – Guilford of Maine – FR701 | FabriTRAK® System | FabriFill | 20 | 250 | Yes |
| 1/2" | None | 12743 – FabriSPAN™ Fabric | EZ Span™ System | 6 PCF Fiberglass | 20 | 300 | Yes |
| 1/2" | None | 13985 – Guilford of Maine – FR701 | FabriTRAK® System | FabriFill | 15 | 200 | Yes |
| 1/2" | None | 12745 – Knoll Mezzo | FabriTRAK® System | 6 PCF Fiberglass | 15 | 145 | Yes |
| 1/2" | None | 12746 – Guilford of Maine – FR701 | FabriTRAK® System | 6 PCF Fiberglass | 15 | 120 | Yes |
| 1/2" | None | 12744 – Guilford of Maine – Bailey | FabriTRAK® System | 6 PCF Fiberglass | 15 | 45 | Yes |
| 1/2" | None | 12905 – Guilford of Maine – FR701 | FabriTRAK® System | FabriFill | 10 | 180 | Yes |
| 1/2" | None | 12742 – FabriSPAN™ Fabric | EZ Span™ System | Willtec® | 10 | 400 | Yes |
THE FABRITRAK® SYSTEM
CHOOSE A TRAK PROFILE
Customize the space with fabric in any color, style, and texture
FabriSPAN® offers a complete collection of fabrics available in wide width (10') and ultra-wide widths (16'). Most fabrics can be custom dyed to any color or image - affording the designer total creativity in an interior space.
- FabriSPAN® : wide width and ultra-wide width fabrics
- FabriPRINT™ : FabriART™ and FabriPATTERN™
- FabriFELT™ : 100% natural wool felt, available upon request
CHOOSE AN INFILL
Infill materials offer superb sound control solutions
Acoustic infills contribute to the NRC ratings of the entire FabriTRAK® System. TerraCORE® Poly and FabriTACK® are sound absorbing products that have their own benefits when included in the FabriTRAK® System. FabriBLOK® is used in the FabriTRAK® System as a noise isolation barrier.
- Terracore® Poly
- Fabriblok®
CHOOSE A FABRIC
Customize the space with fabric in any color, style, and texture
FabriSPAN® offers a complete collection of fabrics available in wide width (10') and ultra-wide widths (16'). Most fabrics can be custom dyed to any color or image - affording the designer total creativity in an interior space.
- Fabrispan® : Wide Width And Ultra-wide Width Fabrics
- Fabriprint™: Fabriart™ And Fabripattern™
- Fabrifelt™ : 100% Natural Wool Felt, Available Upon Request
