Oikos Synua Safety Door
SYNUA SAFETY DOOR
SYNUA SAFETY DOOR
The safety door for large dimensions, with vertical pivot operation and installation coplanar with the wall.
Synua is the safety door that knows no limits: ideal for large sizes, it is the perfect combination of technology and design.
Equipped with pivoting opening, and coplanar with the wall, it is covered by sectors or by a single panel or by a solution upon customer drawing, and can reach up to 3000 mm of width and 6200 mm of height in its standard versions. Upon request it can feature even larger dimensions.
INFORMATION
APPLICATIONS
Residential
WINDOW TYPE
Pivot
USE
Safety door with vertical pivot
COLORS
Absolute Black Laminam
OPENING
L push or Manual mechanic
EXTERNAL-INTERNAL
SWS
SIZES
1540 x 2960 mm
EXTERNAL-INTERNAL COVERING
Absolute Black Laminam
SHAPES
Synua is available in the two versions with single leaf or with side panel.
MOUNTING
Internal-external flush with the wall
USE IN CONSTRUCTION
Facades
DOOR
Synua
BRAND
Oikos
PRODUCT TYPE
Door
PRODUCTION
Made in Germany
CHARACTERISTICS
- Heat Barrier Frame And Leaf
- Motorized Electronic Lock
- Automatic Opening
COVERING
- Line Piano
- Line Fugato
- Line in sectors
- Custom
- Skydoors
SAFETY DOOR WITH PIVOT HINGES WITH
- Maximum feasible size: 3000x6200mm (greater on request)
- Covering with sectors, single panel or upon customer design
- Version with heat barrier frame and leaf (optional)
- Motorized electronic lock with integrated access control system on request
- Automatic opening with floor motor for doors weighing up to 560 kg on request
OPTIONAL FEATURES
-Opening Type : Arckey system, Card Reader, Touchpad, Fingerprint Reader, Smartphone
-Synua handle and long handle : Sliding handle, Jumbo handle, Cortina long handle, Long handle and Ceg model
-Skydoors long handle : Long handle Orizzonte model, Long handle Direttrice model
-Synua Wall System - Boiserie : External covering, Synua and Internal covering, Synua
-Heat barrier frame : Thermal insulation, Synua 3TT
-Fire-barrie : Fire resistance
-Hurricane-proof : Hurricane certification
-Floor closing element (or draught excluder) : Standard draught excluder, Mose Kit and Dam Kit.
SPECIFICATIONS
| PERFORMANCE | STANDARD | UPON REQUEST |
|---|---|---|
| Break-in resistance | Class 3 | - |
| Thermal | 1.6 | 1.3 |
| Acoustic | 38dB | - |
| Air | 2 | Mose Kit 4 |
| Water | 0 | Mose Kit 5A |
| Wind | C4 | Mose Kit C5 |
| fire | - | EI 60 / VKF 60 / EI 120 / UL-FD 120 |
| Hurricaneproof | - | Hurricaneproof Noa |
FINISHES
SKYDOORS
INTERNAL WOOD
MATERICI
EXTERNAL WOODS
LEGNO VIVO
LACQUERED
OPEN PORE LACQUERED
POLISHED GLASS
MATT GLASS
LAMINAM
ALUMINUM
METALLIC LACQUERED
FASHION
THE NATURAL STONE
DETAIL
FREEDOM IN THE TERM OF SIZE
Synua, the safety door with vertical pivot, allows a wide freedom in terms of sizes, ideal for large entrances, designed to follow the trends of contemporary living.
OWNER'S KEY BOX
All Oikos safety doors are supplied with a building site key to be used for production checks and by technicians entrusted with installation tasks. The owner's keys, on the other hand, are always supplied sealed inside a special elegant box.
PIVOTING OPENING OF THE DOOR
The opening and closing of the door take place by means of a vertical pivot, i.e. two pins placed at the ends, which are adjustable and concealed. The leaf, by turning on itself, allows a wider opening and greater brightness.
AUTOMATIC OPENING FOR FLOOR MOTOR
Electronics components are designed to allow for maximum refinement of movement, conceived mainly for large pivoting doors. Management system configurable with the Oikos Arckey App.
SYNUA WALL SYSTEM
The Synua Wall System exploits the perfect coplanarity of Oikos doors in order to create walls that share the same aesthetic concept. Consisting of modular sectors that can be covered with different materials, SWS creates spectacular wall systems. A wall-door that combines the scenic and aesthetic effect with safety, elegance, and protection.
