Western Window Systems Series 7650 Sliding Glass Door
SERIES 7650 SLIDING GLASS DOOR
WINDOW SYSTEMS SERIES 7650 SLIDING GLASS DOOR
The Series 7650 Sliding Glass Door features large, energy efficient glass panels that maximize natural daylight and views. Available with panels up to 15 feet tall in many applications.
It is easy to operate, thanks to sealed stainless steel ball bearing rollers, and the aluminum frame’s clean lines, narrow profile, and high-quality anodized or painted finishes deliver a contemporary aesthetic that seamlessly blends into nearly any space.
- Extreme opening sizes
- Industry Leading U Factors
- Narrow 2.9” Sightlines at Interlocks
- Multiple Sill Height Options
- Premium Hardware and Roller Options
INFORMATION
CERTIFICATIONS
- NFRC
- AAMA
- California's Title 24 compliant
UNIFORM LOAD DEFLECTION (PER ASTM E 330)
50 psf
CRF FRAME (PER AAMA 1503)
71
USE
External partitions
CSA A440 AIR
A2
WATER RESISTANCE (PER ASTM E 547)
8.0 psf
AIR INFILTRATION (PER ASTM E 283)
15 cfm/sf @1.57 ps
AAMA PRODUCT DESIGNATION (AAMA/WDMA/ CSA101/I.S.2/A440 DESIGNATION)
LC-PG50-144x120-SD
UNIFORM LOAD STRUCTURAL (PER ASTM E 330)
75 ps
FRAME DEPTH
5 7/8”
FORCED ENTRY RESISTANCE
ASTM F842 Type B Grade 10
U-FACTOR (PER NFRC 100)*
0.30
TEST CONFIGURATION
144” x 120” OXO
CR (PER NFRC 500)*
57
COLLECTION
Window Systems
APPLICATIONS
- Door and Window
- Systems for Residential
- Commercial
- Corporate
- Hospitality
CHARACTERISTICS
- Energy Efficiency
- Low-maintenance
- Smooth Operation
- Durable
- Customizable Options
FINISHES AND COLORS
Finishes are available in-stock or as designer selections, and they can be customized to match nearly any color. Split painted finishes are available in many combinations. Bronze Anodized and Satin Anodized come standard with a Class 1 coating thickness for increased smoothness and durability. Our designer colors include a high-quality paint finish that conforms to a minimum rating of AAMA-2605, currently the highest rating for organic finishes.
WATER BARRIERS
