SLIDING WINDOWS
SLIDING WINDOWS
Opt for simplicity and free your imagination, with infinite adaptability.
The sliding window is a unique horizontal opening solution.
The structure is anodised 25 micron aluminium alloy, in a natural colour finish. As an option, the thermolacquered or anodised versions are available in an infinite choice of colours. The roller bearing system is made from stainless steel specially adapted for projects near the sea.
Fixed or sliding, the width of the vertical profile is 22 mm and is only limited by the maximum surface area of the glass. Button-locking available with two-point locking and cylinder locking with key. Motorisation possible.
INNOVATION
Single-track insulated invisible frame.
Set on a single track, the sliding window allows its entire surrounding frame to be concealed. The exceptional finishes provide incomparable transparency on all four sides. And the expansive openings offer maximum light with the fewest possible visible profiles.
The glazing and surface options are infinite. This new window creates space, light and freedom: the architectural barrier between inside and out ceases to exist.
This insulated invisible frame is available in a range of options: with one or several tracks, to meet the latest requirements.
The single-track insulated invisible frame is a feat of engineering which combines flexibility with simplicity and quality. Always tailor-made, the minimalist sliding window offers a very attractive and varied scope of use. It can be adapted to different glass formats and demanding climates, and is designed to ensure an unimpeded view. The design has been patented.
APPLICATIONS
CURVED
The curved application supports a radius of 3 metres for mobile elements and 1.5 metres for fixed.
POCKET
It is possible to conceal one or more sliding panels in a closed and isolated space.
INVISIBLE FRAME
This application removes the need for an internal or external architectural enclosure. It features 32 or 44 mm double or triple glazing, and sliding window surfaces of up to 18 m².
OPEN ANGLE
This solution frees the angle from any jambs. All combinations of rails are possible, for example a combination of two and three rails.
RANGE -TH+
THERMAL INSULATION AND LARGE SURFACE AREAS
- Available in 32 or 44 mm double or triple glazed versions, the Vitrocsa TH+ range is for sliding window surfaces of up to 18 m2, with scope for larger panes, depending on the supplier of the glass.
- The excellent insulating properties of the profiles, in combination with the glass, enable current low energy consumption standards to be met.
CONFIGURATION
- Standard sliding frame (up to 18 m2, or more)
- Sliding invisible frame (up to 18 m2, or more)
- Curved (sliding: minimum radius of 3 m; fixed: minimum diameter of 1.5 m)
- Pivoting (up to 12 m2)
- Guillotine (up to 500 kg per pane)
- Turnable Corner (up to 250 kg per pane, 6 m2)
- Fixed (up to 18 m2, or more)
- Opening angle
- Pocket
- Motorisation
- Mosquito net
RAIL + FRAME
- Available in 32 or 44 mm double or triple glazed versions, the Vitrocsa TH+ range is for sliding window surfaces of up to 18 m2, with scope for larger panes, depending on the supplier of the glass.
- The excellent insulating properties of the profiles, in combination with the glass, enable current low energy consumption standards to be met.
CLOSURE MECHANISM
- One-point closure button (029, 035, 055)
- Two-point closure button (092)
- Three-point closure button
- Cylinder
- Range of options for electric closure
- Alarms
VERTICAL CONNECTION
- 22 mm
- Reinforced for very windy locations or installation at high altitudes
GLAZING
- 32 mm or 44 mm
- Panel size up to 18 m2 (6 x 3.21 m), with scope for larger panes, depending on the supplier of the glass, vertical or horizontal
DOWNLOADS
↓ Data Sheet
↓ Certificates
RANGE -3001
FLAGSHIP RANGE
- The Vitrocsa 3001 range allows for sliding window surfaces of up to 6 m² with 26 mm double glazing.
- The first Vitrocsa 3001 window was developed at the start of the 1990s. With the experience we now have, we can guarantee that this system presents no hidden defects.
- The roller mechanism and sealing system work perfectly, provided that the window has been assembled in line with good industry practices.
RAIL + FRAME
- Embedded and concealed in the floor, wall and ceiling
- Rails just 99.5 mm wide for a birail (mono : 45 mm + 9.5 mm seal)
- Saline treatment specially adapted for coastal projects
GLAZING
- 26 mm
- Panel size up to 6 m2
VERTICAL CONNECTION
- 18.5 mm
- Reinforced for very windy locations or installation at high altitudes
DOWNLOADS
↓ Data Sheet
↓ Certificates
CLOSURE MECHANISM
- One-point closure button (029, 035, 055)
- Cylinder
- Range of options for electric closure
- Alarms
CONFIGURATION
- Standard sliding (up to 6 m2)
- Pivoting (up to 6 m2)
- Guillotine (up to 6 m2)
- Fixed (up to 9 m2)
- Opening angle
- Pocket
- Mosquito net
RANGE - SWIMMS
HOT COUNTRIES AND INTERNAL PARTITIONS
The profile assembly system enables a range of glazing thicknesses to be used: 10-12 mm or 16-20 mm. The Vitrocsa SWIMMS range is ideal for hot countries or internal partitions.
CONFIGURATION
- Standard sliding
- Opening angle
- Pocket
VERTICAL CONNECTION
- 17.2 mm
- Reinforced for very windy locations or installation at high altitudes
CLOSURE MECHANISM
- Two-Point Closure Button (092)
- Cylinder
- Range Of Options For Electric closure
- Switchs, Alarms
RAIL + FRAME
- Embedded and concealed in the floor, wall and ceiling
- Rails just 64 mm wide for a birail (mono: 32 mm)
- Saline treatment specially adapted for coastal projects
DOWNLOADS
↓ Data Sheet
↓ Certificates
GLAZING
10 to 20 mm (single-glazing)
RANGE - V32
SLIM PROFILE AND THERMAL REINFORCEMENT
The V32 range has thermal reinforcement and a glass fibre profile. This range is designed for standard fixed or sliding openings.
CONFIGURATION
- Standard Sliding (up to 12 m2)
- Fixed (up to 12 m2)
- Opening Angle
- Pocket
RAIL + FRAME
- Embedded and concealed in the floor, wall and ceiling
- Thinner rails just 124 mm wide for a birail (mono: 56 mm + 12 mm seal)
- Saline treatment specially adapted for coastal projects
CLOSURE MECHANISM
- Two-point closure button (092)
- Cylinder
- Range of options for electric closure
- Alarms
GLAZING
- 32 mm
- Panels up to 12 m2 (4 x 3 m), vertical or horizontal
VERTICAL CONNECTION
- 23 mm
- Reinforced for very windy locations or installation at high altitudes
- Optimised heat retention with fibreglass towers
DOWNLOADS
↓ Data Sheet
↓ Certificates
RANGE -V56
INFINITE SURFACE
- The Vitrocsa V56 range allows infinite glazing surfaces using 56 mm thick double or triple glazing. The V56 range is an evolution of our current sliding window systems.
- The Vitrocsa V56 window has been developed to keep the same mechanical characteristics of the Vitrocsa systems which have been proving their worth for over 25 years.
RAIL + FRAME
- Embedded and concealed in the floor, wall and ceiling
- Saline treatment specially adapted for coastal projects
CONFIGURATION
- Standard Sliding
- Pocket
- Opening Angle
GLAZING
56 mm In Double Or Triple Glazing
CLOSURE MECHANISM
Two-Point Closure Button (092)
VERTICAL CONNECTION
- 22 mm
- Reinforced for very windy locations or installation at high altitudes
