3m™ Dichroic Glass Finishes Df-pa Chill, 48 In X 98.4 Ft
The “Chill” Product shift colors in the cool tones of blue/magenta/yellow in transmission and gold/green/blue color regions of the spectrum in reflection.
The product appears to change color when viewed at various angles. A hard coated surface layer helps resist scratching. Materials: Constructed from durable and flexible polyester materials. Create one of a kind architectural masterpieces at a fraction of the cost of color shifting glass.
Suggested Applications :
- Conference Rooms
- Lobbies
- Retail Environments
- Partitions
- Verandas
- Private Offices.
3M™ DICHROIC™™ Glass Finishes DF-PA (the “Products”) offer a way to create unique, ever changing color on many interior and exterior building glass surfaces. Influenced by the color of the substrate, these transparent Products provide a dichroic color effect, meaning they appear to change color when viewed at various angles.
The “Blaze” Product shifts colors in the warm tones of cyan/blue/magenta in transmission and red/gold color regions of the spectrum in reflection. The “Chill” Product shifts colors in the cool tones of blue/magenta/yellow in transmission and gold/green/blue color regions of the spectrum in reflection.
-The Products have a clear, pressure-sensitive adhesive that can be applied to glass. A hard-coated, protective surface layer helps resist scratching during normal use. -The Products can be used in applications on the surface of interior glass, interior perimeter glass (the “Interior Applications”), and vertical exterior glass (the “Exterior Applications”)
INFORMATION
ADHESIVE FEATURES
Pressure-sensitive
ADHESIVE TYPE
Acrylic
BRAND
3M™
DESIGN PATTERN
Dichroic
FEATURES
LEED Points
COLOR FAMILY
Multi-color
LINE
Dichroic Glass Finishes
OPACITY
Transparent
FILM TYPE
Multi-layer Polymeric
APPLICATION METHOD
- Method : Wet
- Surface : Flat
FILM THICKNESS
- Imperial : 5 mil
- Metric : 127 micron
REMOVABILITY
Removable with low heat/adhesive remover
SIZE (IMPERIAL)
32.8 yd x 48 in x 5 mil, 48 in x 32.8 yd
SIZE (METRIC)
30 m x 1220 mm x 0.127 mm, 1220 mm x 30 m
APPLICATIONS
Windows, glass surfaces
CHARACTERISTICS
Available in either warm or cool tones, changes color depending on viewing angle
MAXIMUM ROLL SIZE
48 in. X 98.4 ft. (1220mm x 30m)
DIMENSIONS
- Overall Length Imperial/ Metric : 32.8 yd/30 m
- Overall Thickness Imperial/ Metric : 5mil/0.127mm
- Overall Width Imperial/ Metric : 48 In/1220 mm
USE
Interiors
SPECIFICATIONS MET
Class A - ASTM E84 Fire Classification, CSI Division 08
VISIBLE LIGHT
- Reflectance : 78 %
- Transmittance : 17 %
PRODUCT COLOR
Multi-color
SHADING COEFFICIENT
0.77
PERFORMANCE LEVEL
Premium
SUBSTRATE
Glass
SURFACE FINISH
Glossy
TDS REQUIRED
Yes
FEATURED BENEFITS
-Create dynamic, color-shifting appearance in cool or warm tones influenced by the environment. -Transparent dichroic color effect changes color when viewed from different angles -Easy application - wet application method of DF-PA virtually eliminates air bubbles, simplifying and speeding up application. -Expected Performance Life of 10 years for interior applications on non-perimeter glass, 7 years for interior perimeter glass, 5 years for vertical exterior glass (see Warranty
