Polysto Renopanel
RENOPANEL
RENOPANEL
RenoPanel is a combined panel. RenoPanel is compliant with HACCP regulation and the connection is made with an omega profile.
INFORMATION
PRODUCTION
Made in Belgium
CUSTOM DIMENSIONS
On demand
WEIGHT
1800 g/m²
STRAIN AT BREAK
7 - 12 %
VICAT SOFTENING POINT
150 °C
POLYPROPYLENE THICKNESS
10 mm
TYPE
Panels
SIDES
Straight
HARDNESS
30 - 40
TEMPERATURE RANGE
- 0°C
- +60°C
SURFACE STRUCTURE
- Embossed
- Smooth
FIRE CLASS
- Euro Class E
- Euro Class C-s3,d0
POLYESTER THICKNESS
- 1.5 mm
– 2 mm
– 2.3 mm
HEAT DEFLECTION TEMPERATURE
85 - 95 °C
THERMAL EXPANSION
8.0 - 10 *10-5 cm/cm°C
FIRE CLASSIFICATION
- S2-d0
- Available in euroclass E and euroclass B
PANEL MATERIAL
Polypropylene
DENSITY
0.900 - 0.905 g/cm²
TOLERANCE
- Length : ± 3 mm
- Width : ± 1 mm
- Thickness : ± 0.1 mm
FLEXURAL MODULUS
1200 - 1450 N/mm²
TENSILE STRENGTH YIELD
27 - 28 MPa
APPLICATIONS
- For renovation and new-build.
- Because of the weight ideal for the renovation of ceilings.
STANDARD COLOUR
- Ral 9016 White
- RAL 9016 Blanc
CUSTOM FINISHING
- Smooth Extra (Glossy)
- Smooth Extra Mat (Mat)
- Woven Matt (Extra Strong)
STANDARD DIMENSIONS
- 2.5 x 1.2 m (3 m2)
- 3 x 1.2 m (3.6 m2)z
- 2.75 x 1.2 m (3.3 m2) – only embossed
THE PANEL IS COMPOSED OF 2 PARTS
- Part I = Polypropylene corrugated sheet
- Part II = FRP sheet Euroclass E
ADVANTAGES
- Water Resistant And Waterproof (Nbn 492)
- Resistant To Many Chemicals
- Resistant To Many Living Organisms (Fungi, Bacteria, Insects, Vermin)
CHARACTERISTICS
-Food safe -Chemical Resistant -Economical Ecological -Anti-fungal Anti-bacterial -Water and Dirt resistant -Easy to Clean -Assumes no odors -Non-corrosive -High impact-and scratch proof -Quick and easy to install -Cooled and heated spaces -Optional Fire Retardant, standard Euroclass E -Anti-graffitiDoesn’t discolour -All RAL colours, standard RAL 9016 (Hygienic white) -Easy reparable
