Line Systems Glass Slim U
GLASS SLIM U
GLASS SLIM U
Glass Slim U was conceptualized with a strong aesthetic and technical mindset.
which enabled the development of a demountable wall system that not only compartmentalizes space but also provides a true minimalist look to any workplace.
INFORMATION
PROFILE DIMENSIONS
39x50mm (w x h)
GLASS
10, 12 or 16mm Glass
GLASS CONNECTION
180º, 90º or T PETG profiles
TYPE
Frameless Single Glazed
TOLERANCE
+/- 20mm. Up to 35mm upon consultation
DIMENSIONS
Glass Slim U isn´t only an aesthetic and competitive solution like most single glazed products in the market, as it is also a very strong technical product allowing for installation tolerances over 20mm, and the use of 10, 12 or 16mm glasses.
DOWNLOAD
↓ Product Sheet
INSTALLATION
Glass Slim U isn´t only an aesthetic and competitive solution like most single glazed products in the market, as it is also a very strong technical product allowing for installation tolerances over 20mm, and the use of 10, 12 or 16mm glasses.
GLASS SLIM U "FACTORY EDITION"
Glass Slim U was conceptualized with a strong aesthetic and technical mindset, which enabled the development of a demountable wall system that not only compartmentalizes space but also provides a true minimalist look to any workplace.
ACOUSTIC PERFORMANCE
36 dB with a 10.2 Acoustic Laminated Glass
MODULATION LENGTH
- Between 200 and 1200mm.
- Other lenghts possible upon consultation
MODULATION HEIGHT
- Up to 3500mm (h) for 12mm glass
- >3500mm for 16mm possible
DOOR OPTION
40/50mm Opaque Door, 10mm Single Glass Door, WOD Glass Slim Framed Single Glazed / Double Glazed / Opaque
