Italmesh Roma Wall Panels
ROMA WALL PANELS
ROMA
Wall Panels
INFORMATION
ROMA 65
STEEL KG/M2
- 3,35
- 5,60
- 8,20
ALUMINUM KG/M2
- 1,15
- 1,90
- 2,80
MAXIMUM WIDTH OF SHEET / COIL MM:
Steel / Aluminium
- 0,6 - Width 1000 – 1250 – 1500
- 1 - Width 1000 – 1250 – 1500
- 1,5 - Width 1000 – 1250 – 1500
MESH MM
- R62 x 23 – 8 x 0,6
- R62 x 23 – 8 x 1
- R62 x 23 – 8 x 1,5
FRONTAL OPEN AREA APROX
36%
ROMA 85
STEEL KG/M2
- 7,40
- 9,87
ALUMINUM KG/M2
- 2,55
- 3,40
MAXIMUM WIDTH OF SHEET / COIL MM:
Steel / Aluminium
- 1,5 - Width 1000 – 1250 – 1500
- 2 - Width 1000 – 1250 – 1500
MESH MM
- R85 x 35 – 11 x 1,5
- R85 x 35 – 11 x 2
FRONTAL OPEN AREA APROX
48%
ROMA 100
STEEL KG/M2
- 8,80
- 11,75
ALUMINUM KG/M2
- 3,00
- 4,00
MAXIMUM WIDTH OF SHEET / COIL MM:
- 1,5 - Width 1000 – 1250 – 1500
- 2 – Width 1000 – 1250 – 1500
MESH MM
- R100 x 30 – 11 x 1,5
- R100 x 30 – 11 x 2
FRONTAL OPEN AREA APROX
30%
ROMA 105
STEEL KG/M2
- 7,55
- 10,10
ALUMINUM KG/M2
- 2,70
- 3,50
MAXIMUM WIDTH OF SHEET / COIL MM:
- 1,5 - Width 1000 – 1250 – 1500
- 2 - Width 1000 – 1250 – 1500
MESH MM
- R100 x 35 – 11 x 1,5
- R100 x 35 – 11 x 2
FRONTAL OPEN AREA APROX
45%
