PENTA W.A. ROOF PANEL
PENTA W.A. ROOF PANEL
Self-supporting roof panel with rockwool insulation and internal micro locked support, used for industrial, commercial and civil buildings.
With the need to have sound insulation and sound absorption characteristics. The panel has to be assembled with a 7 % minimum slope.
INFORMATION
WORKING WIDTH
1.000 mm
LOCKED
Internal Support Micro Locked
THICKNESS (MM)
- 50 – 60 – 80 – 100 – 120 – 150 – 200
DIMENSIONS
-5 Ribs -40 mm Ribs Height -250mm Ribs Step
FIRE RESISTANCE ACCORDING TO UNI EN 13501-2 (*)
- Th. 100 mm – R.E.I. 90 – Assembled as roof panel;
- Th. 100 mm – E.I. 60 – Assembled as wall panel;
MICRO LOCKED SHEET
15 %
TYPE
Roof Panel
HOLES STEP
5 mm
HOLE DIAMETER
3 mm
DETAILS
