Graff Luna Shower
LUNA SHOWER
LUNA SHOWER
A gleaming crescent moon
Arched to perfection, the sleek crescents of the Luna Collection carry over into the thermostatic shower system. A wall-mounted base with an overhead rainfall setting, the Luna shower may be used every day but will never feel routine.
INFORMATION
FLOW RATE INFORMATION
The 3/4” thermostatic mixing valve has a flow rate of 58 l/min. at 3 bar.
DOWNLOADS
↓ Dimensional drawing
↓ Exploded diagram
↓ Part list
↓ Installation instructions
↓ 3d file
↓ Collection catalog (Luna)
↓ Symbologies
TOOLS AND MATERIAL
- Tape Measure - Pencil - Drill - Blade Screwdriver - Philips Screwdriver - Hex Wrenches - Level - Silicone Sealant
DIMENSIONS
Height : 840 mm
FINISHES
- Polished Nickel - Polished Chrome - Brushed Nickel - Matte Black - Architectural Black - Architectural white - Satin Nickel
CAREFUL INSTRUCTIONS
Carefully unpack and inspect all the components for damage. To protect against damage, return all components to the carton until ready to install.
VOLUME
Single-handle wall-mount stop/volume control valves are of brass construction. Products feature 3/4” quarter-turn washerless ceramic disc valve. Products also feature R3/4” female connections.
