IGLOO TYPE 1
IGLOO TYPE 1
What is more exciting than young tiny tots exploring through their imaginations filled with beautiful Canadian sculpted igloos attached to a slide. Lots of room for adventure, rope play and climbing.
FEATURES
SUPPORT POSTS:
This will be 3 1/2" (90mm) OD schedule 40 galvanized steel pipe, finished with polyester coating
BALL KNOTS:
This will be a one-piece compressed aluminum ball, compressed in place with 150,000 pounds force (667 kN) to prevent the connection from moving and causing premature cable wear.
DECKING
This will be constructed of custom cut 3/16" (5mm) thick punched steel decking with 2" (50mm) angle frame, 3/16" (5mm) thick, welded perpendicular to the deck surface for support. Deck sections are dipped in a phthalate-free PVC coating.
SLIDE MATERIAL:
This will be UV protected LLDPE (linear low-density polyethylene).
CLIMBING NETS:
These will be 20 mm diameter, polyamide (nylon) rope cable with UV protection and fire retardant solution. Each rope consists of 6 strands each containing 24 galvanized steel reinforcing strands within a polyamide sleeve, wrapped around a solid polyamide core for a total of 144 steel reinforcing strands; each end of the cable having a junction loop attached onto the cable with a finished aluminum sleeve and lined with a galvanized steel wear bar. Rope shall achieve a Class 7-8 Colourfastness rating.
RUBBER SURFACES:
This will be 1/2" (13mm) thick textile-reinforced rubber belt.
BASIC FASTENERS:
All fasteners for component attachments are stainless steel.
INSTALLATION:
This should be installed only by a licensed playground installer, trained and certified on the relevant playground standards in place in the region of installation, e.g., NPSI, CPSI or similar certified.
INFORMATION
DIMENSIONS
- Length 5.03 m / 16' 6"
- Width 4.34 m / 14' 3"
- Height 2.80 m / 9' 2"
WEIGHT
950 kg / 2094.4 lb
DOWNLOADS
VOLUME
12.00 m3 / 423.8 ft3
FOUNDATION
2
CONCRETE VOLUME
0.64 m3 / 22.6 ft † 3
ASTM F-1487
2 years - 5 years
- 16
- 8.68 m / 28' 6"
-0 7.98 m / 26' 2"
- 1.56 m / 5' 1"
CSA Z614
18 months - 5 years
- 16
- 8.68 m / 28' 6"
- 7.98 m / 26' 2"
- 1.56 m / 5' 1"
EN 1176
3 years - 6 years
- 16
- 8.09 m / 26' 7"
- 7.38 m / 24' 3"
- 1.56 m / 5' 1"
OPTIONS
DETAILS
Where proper surfacing is used, this product meets the ADAAG guidelines for accessibility, allowing the same play possibilities for people of all abilities.
