JUNO
JUNO
Robust Design With Sleek Finish
Juno feeder pillars provide electrical services for markets, squares, hotels, and parks etc. as well as marinas and other public or private areas.
- Supplied with hinged door(s) and flange plat
- Available in either stainless steel (grade 304) in a brushed finish or galvanised steel finished in any standard RAL colour
- Non-standard versions (eg different heights or door sizes) are available to special order
INFORMATION
MATERIAL
Galvanised steel OR Grade 304 Stainless steel (Grade 316 on request)
FINISHES
- Galvanised steel: Polyester powder coat
- Stainless steel: Machine brushed
COLORS
- Galvanised steel: RAL 9017 Traffic black
- Stainless steel
- Other RAL colours available on special request
MOUNTING
- Flange plate
- Bolt on root available separately
AVAILABLE WITH ELECTRICAL ACCESSORIES
Juno feeder pillars may be supplied complete with electrical equipment or empty (without backboard). Please contact us for more information.
DIMENSIONS
| NAME | DIMENSIONS | WEIGHTS (KG) |
|---|---|---|
| Juno 1 | Height: 1000, Shaft: Ø170, Flange plate: Ø240 | 20 |
| Juno 2 | Height: 1000, Shaft: Ø170, Flange plate: Ø240 | 20 |
| Juno 3 | Height: 1000, Shaft: Ø220, Flange plate: Ø300 | 31 |
| Juno 4 | Height: 1000, Shaft: Ø325, Flange plate: Ø420 | 64 |
| Juno 5 | Height: 1000, Shaft: Ø325, Flange plate: Ø420 | 64 |
| Juno 6 | Height: 1300, Shaft: Ø325, Flange plate: Ø420 | 81 |
