Moderco Excel 700 Operable Partition
EXCEL 700 OPERABLE PARTITION
EXCEL 700
Operable Partition
Excel is your best choice if a competitively priced, precisely engineered operable partition fits your needs.
Excel (formerly 700 Series) is robotically assembled thus guaranteeing precise engineered dimensional and consistent quality. Each panel frame is fully welded utilizing heavy gauge galvanized steel.
The trimless panels skins can be steel, welded to the frame or a steel reinforced tackable surface also welded to the frame panel.
Excel is available in single (right angle or switch and curve operation), paired center stacking or continuously hinged electric configurations. Independently tested full size specimens based on current ASTM test procedures have achieved STC values of 43, 48, 50 and 54. If your partition needs include proven field performance and durability combined with a competitive price point Excel is your best option.
INFORMATION
TECHNOLOGY
The Moderco 700 series offers a technologically advanced,
OPTIONS
The Moderco Excel 700 series product offers numerous optionsincluding marker boards, eraser pockets, same construction pass thru doors and inset exit signs. Consult with your localModerco distributor or visit www.moderco.com for more details
SEALS
Automatically setting and retracting bottom seals provide 2
SEALS TYPE
- FA: Fixed top 1" (25mm) and automatic bottom 2" (50mm) floor clearance
- FV: Fixed top 1" (25mm) and bottom adjustable 3" (76mm) floor clearance
FEATURES
This combination of features together with the Moderco Excel
- Multiple contact top fixed sweep seals
- Structural butt hinges
- Double reinforced welded steel carrier support
- Heavy-duty welded steel frame
- Welded acoustical steel faces
- Standard vinyl, fabric and carpet finishes
- Deep nesting reversible vertical aluminum astragal system with
- Vertical wrap around finish with no vertical edge trim
- 2” (50mm) clearance automatic bottom seals
- Adjustable bottom seals end caps
CONSTRUCTION
The basic panel construction is combined with wraparoundfinishes for a trimless, monolithic appearance. Deep interlockingvertical astragals at all panel joints align panels ensuring asmooth wall face while providing an acoustic seal. Optionalprotective edge trims are available.
MODEL SELECTIONS
| MODELS | 741 | 742 | 743-E | 733-EG |
|---|---|---|---|---|
| Operation | Individual | Paired | Continuously hinged, electrically operated | Continuously hinged, |
| Configuration | Remote/Side | Center | Center | Center |
| Thickness | 4’’ (102mm) | - | - | - |
| PANEL FRAME | Steel frame with trimless or protective edge trims | Steel frame with trimless or protective edge trims | Steel frame with trimless edges | Steel frame with trimless edges |
| STC | 43, 48, 50, 54 | 43, 48, 50, 54 | 43, 48, 50, 54 | 43, 49 |
| Finish Options | Vinyl, Fabric, Carpet, Customer owned or specified material, | Vinyl, Fabric, Carpet, Customer owned or specified material, | Vinyl, Fabric, Carpet, Customer owned or specified material, | Vinyl, Fabric, Carpet, Customer |
| MAX. Height | 16′-3” (4953mm) | 16′-3” (4953mm) | 16′-3” (4953mm) | 33′-3” (9220mm) |
| Panel Width | min. 24” (609mm) max. 48 1/2”(1230mm) | min. 24” (609mm) max. 48 1/2”(1230mm) | min. 24” (609mm) max. 48 1/2”(1230mm) | Min. 24” (609mm) Max. 49 1/4” |
| Panel Weight | 5,5 to 9,2 lbs./sq. ft. [27 to 45 kg/sq.m] | 5,5 to 9,2 lbs./sq. ft. [27 to 45 kg/sq.m] | 5,5 to 9,2 lbs./sq. ft. [27 to 45 kg/sq.m] | 4,1 to 5,1 lbs./sq. ft. (20 to 25 |
| Closure | Telescopic panel or hinged closure panel | Telescopic panel or hinged closure panel | Side jamb or pocket door | Wall jamb or pocket door |
| Seals | FA | FA | FA | FV |
| TRACK | #23-T, #33-T, #55-T, #72 | #45-T, #55-T, #72 | #55-T | #80 |
