Modernfold ComfortDrive® Automated Self-Driving Panel System
COMFORTDRIVE® AUTOMATED SELF-DRIVING PANEL SYSTEM
COMFORTDRIVE® AUTOMATED SELF-DRIVING PANEL SYSTEM
Movable Glass Wall Systems
Convenience and automation are two highly desired features of movable walls. With ComfortDrive®, Compactline® glass panels can be moved to a variety of individually pre-programmed positions under fully automatic control.
The control interface takes the form of a user-friendly touch pad that can be programmed to maximize your space in a variety of applications.
INFORMATION
MODEL
Compactline® On Comfortdrive® System
RAIL HEIGHT & DESIGN
4.88" (124 mm) Contoured Bottom & Top
OPERATION
Single Panel Automatic
Touchpad
RAIL FINISH OPTIONS
- Clear Anodized
- Satin Stainless
- Powder Coat STD RAL
GLASS OPTIONS
Smoke Gray - Bronze - Etched- Silk Screen- Applique- Low Iron
TRACK OPTIONS
ComfortDrive® Automated System
GLASS THICKNESS
1/2" (13 mm)
STANDARD GLASS
- Clear
- Tempered
MAXIMUM PANEL WIDTH
4' (1219 mm)
MAXIMUM HEIGHT
12' (3658 mm)
MAXIMUM PANEL WEIGHT
325 lbs. (147 kg)
FEATURES
Convenience and automation are two highly desired features of movable walls. The ability to simply press a button and your space is automatically divided into a variety of pre-programmed layouts correctly and efficiently every time is what users desire in today’s hectic world.
The ComfortDrive® Automated Self Driving Panel System from Modernfold does just that. Providing outstanding convenience and flexible space utilization with the beauty and daylighting benefits of Compactline® glass panels. With ComfortDrive®, Compactline® glass panels can be moved to a variety of individually pre-programmed positions under fully automatic control. The control interface takes the form of a user-friendly touch pad which can be programmed to maximize your space in a variety of applications.
ADVANTAGES OF COMFORTDRIVE® AUTOMATED SELF-DRIVING PANEL SYSTEMS:
- Fully automatic operation at the push of a button
- Exceptional convenience with dynamic opening and closing speeds of up to 30 ft. per minute
- Easy operation with user friendly touch pad
- Aesthetically elegant with slender track of just 3.875” in width
- High level of safety ensured by an integrated monitoring system that stops and reverses the panel on contact with an obstacle
- UL® 325 safety-tested and certified
- Smart Control System: Trolley’s communicate with control box while on the move to communicate each panels specific location
- Panels individually programmable for custom configurations
- Micro-processor control (bus system) for activation and monitoring of the operational sequence and functions
- Last panel equipped with an electromechanical lock to prevent unauthorized operation
- In the event of a power failure, panels may be manually operated
- Up to 30 panels per partition system, with up to 164 ft. of track
- Single panel weights up to 325 lbs
- High spatial configuration flexibility
- Segmented and curved track layouts also possible
