Tavapan Creawood Wall And Ceiling Panels

Tue Jun 28, 2022Prefabricated PanelsBeautifyMDF Medium Density FibreboardTavapan SA

CREAWOOD PANELS

CREAWOOD

Wall And Ceiling Panels

Timeless design and excellent absorption values characterize the CREAWOOD panels. Three superposed layers of transverse and longitudinal slits generate an excellent perforation pattern of small rectangles.

Tavapan Creawood Wall And Ceiling Panels

Due to the tongue and groove system, the panels can be strung together unlimitedly. The result is a seamless and light looking design of your wall and ceiling panelling.

INFORMATION

SUPPORT BOARD

MDF

THICKNESS

19 mm

INDIVIDUAL SOLUTIONS

Acoustic fleece

REAR SIDE

- Raw, unlacquered
- Closed or regularly slitted

WEIGHT

- With normal combustible support board: 10.5 kg/m2
- With difficult to ignite support board: 11.0 kg/m2

PRODUCTION

Made in Switzerland

VISIBLE SURFACE

- Veneered - Laminated - Lacquered in RAL/NCS colors

FORMALDEHYDE CONTENT

-E1, corresponding to max. 0.1 ppm -E0 without formaldehyde (max. 0.03 ppm)

FIRE RESISTANCE OF THE SUPPORT BOARD

- Normal combustibility, DIN B2, EN D-s2-d0
- Difficult to ignite, DIN B1, EN B-s2-d0

SURFACES

- Veneered
- Laminated
- Lacquered in RAL/NCS colors

STANDARD FORMATS

2000, 2600, 2780, 3600, 4080 x 199 mm (Covering width = 192 mm)

DOWNLOADS

↓ Datasheet
↓ Documentation
↓ Installation

SURFACE SLITTING

- Axial distance: 8 mm, 12 mm, 28 mm ( Groove width: 4 mm)
- Axial distance: 9 mm, 13 mm, 29 mm (Groove width: 3 mm)
- Axial distance: 10 mm, 14 mm (Groove width: 2 mm)
- Rear side closed or slitted

ADVANTAGES

- Available with support board in fire protection class B1/M1 (flame retardant) and euro class B
- Easy installation with special clamps on tongue and groove
- Large variety of design options
- Wide-range acoustic absorption

T +41 32 4826430 F +41 32 4826440

[email protected]

Tavapan SA

https://www.tavapan.ch

Rue de la Dout 10, 2710 Tavannes, Switzerland
