H-Schubert Imi-Beton Facade Panel
IMI-BETON FACADE PANEL
IMI-BETON FACADE PANEL
The imi-beton facade panel is a high-quality panel material based on basalt stone.
Consisting of a highly compressed rock wool core board and an approx. 1 mm thick, imi-beton mineral coating.
INFORMATION
MATERIAL
- The board material is available in 2 different versions, each in the thicknesses 8 and 10 mm:
FORMATS
2.480 x 1180 mm and 3.030 x 1180 mm optionally also in the width 1.230 mm
Optional width of 1.220 mm: from 100 m², longer delivery times.
SPECIAL DIMENSIONS
You can also have your panels cut to size. The length can vary depending on the requirements of your project. Our panels are available in any length between 1,680 mm and 3,030 mm and in a width 1,230 mm. We will be happy to advise you on the possibilities.
Special dimensions in length: from 300 m², longer delivery times and extra charge.
BOARDS
| EXECUTIONS | WEIGHT |
|---|---|
| Imi-beton facade panels Durable 8 mm | 10.1 ± 1.2 kg/m2 |
| imi-beton facade panels Xtreme 8 mm | 11.3 ± 0.8 kg/m2 |
CUTTING AND PROCESING
Fast, easy and competent: Our processing service.
- Cutting and edge processing - Maximum waste optimisation - Single and serial blanks - Grooves, chamfers, bevels, etc.
Installation, planning and statics are always carried out on site. imi’s services include the assembly, processing and delivery of panels and accessories. Please note the technical data for imi-beton facade panels.
SURFACES
- Imi-Beton : -Decor 120 Smooth Formwork Grey -Decor 224 Vintage Standard -Decor 226 Vintage Anthrazit
- Imi-Rost : -Decor 329 Smooth
- Imi-Sandstone : -Dekor 1053 Sandstone
