Lindner Lindner Free Metal
LINDNER FREE METAL wall cladding
LINDNER FREE METAL
Metal Wall Cladding
We help you with the cladding of walls, columns and pillars with our wall cladding Lindner Free Metal to tailor-made solutions according to your project requirements.
We put on a harmonious ambience with exceptional design variations. For an aesthetic surface, a wide variety of coatings and colours are produced according to customer requirements.
The versatile substructures allows a space-saving accommodation of the building technology or also installation lines effortlessly.
INFORMATION
HEIGHT
- Standard up to 5,000 mm (undivided 3,000)
- Unlimited (when attached to vertical shadow gaps at modular centres load-bearing walls)
CIRCULAR ECONOMY
By implementing the Circular Economy ideology we avoid waste, toxic substances and environmental pollution. The aim is to achieve a technical cycle, which ensures the separation and the complete re-use of all materials.
EPD
A specific EPD(Environmental Product Declaration) for the product can be generated according to the valid standards. (EN 15804/ ISO 14025)
WELL-DESIGNED EQUIPMENT
Micro perforated metal wall shells for optical and acoustic optimization of rooms.
MULTIFUNCTIONAL USAGE
Magnetic surface makes your partition an organizational talent.
DIMENSIONS
- Overall Depth: Approx. 60 mm
- Weight: Approx. 24 - 26 kg/m²
- Joint Width: 6 / 8 mm
REQUIREMENTS
- Statics: Impact Loads, Seismic Safety, Structural Stability
- Acoustics: Longitudinal Sound Reduction, Room Acoustics
- Hygiene: Cleanable by vacuuming, Wipeable
- Corrosion Protection: Interiors
- Sustainability: Environmental Product Declaration
- Fire Protection: Fire Behaviour / Building Material Class
PRODUCT SELF-DECLARATION
The self-declaration provides extensive information about all environmental effects of the product. It can be used in the planning or tender phase to assess all sustainability-relevant aspects. It serves as a data basis for building certification systems such as LEED, DGNB, BNB and BREEAM.
MODULAR WIDTH
Standard up to 1,250 mm
DESIGN
-Aluminium -Digital Print -Glass -Perforation -Power Coating -Stainless Steel -Steel -Varnish
APPLICATIONS
- Workplace: Assembly Rooms, Common Rooms, Facilities for Meetings, Conventions and Conferences, Offices, Utility Rooms, Broadcasting Rooms, Television Studios, Data Centres, Stage and Studio Rooms
- Recreation and Culture: Museums, Places of Assembly, Stadiums, Banks, Sales Areas, Cinemas and Theatres, Concert Halls, Shopping Centres
- Education: Library Rooms, School, School of Higher Education, Research Rooms
- Transport: Airports, Train Stations, Subways and Tunnels
- Healthcare: Clean Rooms, Clinics and Hospitals, Operating Theatres, Pharmacies (Production), Laboratories
- Public Areas: Entrance Areas, Escape Routes
- Public Institutions: Court Houses, Government Buildings
- Hotels and Gastronomy: Hotels and Resorts, Restaurants and Canteens
- Industry: Clean Rooms, Laboratories and Research Facilities
