Condor Scaffolding system with pins
SCAFFOLDING SYSTEM WITH PINS
SCAFFOLDING SYSTEM WITH PINS
The scaffolding system with pins is made up of frames with a PIN coupling system for positioning ledgers and diagonals. Due to its simple assembly it is widely used by construction companies.
Tube and coupler scaffolding can be integrated for special operations. The elements of the prefabricated scaffolding were designed for a simple and safe assembly.
INFORMATION
BRAND
Condor
PRODUCT TYPE
Formwork
COLLECTION
Scaffolding
PRODUCTION
Made in Italy
DIAMETER TUBE
48.3 mm x 2.90mm
STEEL
S235JR
USE
Construction
CERTIFICATIONS
Ministry Authorizations, EN 12810.
ELEMENTS
All the elements of the scaffolding were tested and certified by the I.S.P.E.S.L. Laboratory. (safety technology departments and authorized by the ministry of labour and social affairs with specific authorizations and extensions).
RANGE
The wide range of accessories allows the design of projects meeting the most sophisticated and complex construction and architectural techniques.
SPANS
180 cm
COUPLING
pins
MATERIAL
Steel
ENVIRONMENT
Outdoor
AUTHORIZATION FOR CONSTRUCTION LOADS UP TO
300 daN/mq (cl 4,)
WELDING
An efficient system for the control of weldings makes condor scaffoldings with pins reliable and trustworthy over the time.The scaffolding with pins is recommended for both renovations and new constructions.
